Packaged QFN or Bumped Die on Wafer

Azxon
Silicon

All of Axzon’s sensor solutions are powered by our innovative, ultra-low power sensing technology that allows sensing various physical quantities with the extremely low power harvested from an RFID reader signal.
Another unprecedented breakthrough is the sensitivity of our silicon sensor, which allows reliable sensing and communication with a compatible reader at distances up to 17 meters away.

The self-tuning Chameleon™ front-end on all or our allows our sensors to be placed on a variety of surfaces, without adverse impact to the chip’s sensitivity.

All these features make passive (or battery-free) sensing possible for applications ranging from automotive, industrial, supply-chain logistics and healthcare.

Magnus-3

The first in the family of our smart passive sensing silicon is Magnus, which is used for passively sensing temperature and moisture in a variety of industrial and healthcare applications. Both on-metal and off-metal tags have been designed using Magnus-3 to the suit the needs of the application.

Magnus-3LED Locator RFID Transponder IC

The Magnus-3LED Locator RFID Transponder IC is a fully compliant UHF RAIN transponder IC with the added capability of lighting an LED in response to a Select command.

This feature can be used to locate a tagged object with a known TID or EPC number or to locate a group of tags with a shared field in the TID or EPC. The Magnus-3LED Locator Transponder IC can be read by EPC class 1 gen 2 v2 and ISO/IEC 18000-63 compliant readers, and the LED can be controlled using a protocol compliant Select command.

AZN3300-D Magnus®-S3 M3D Passive Sensor IC

The AZN3300-D Magnus®-S3 M3D Passive Sensor IC extends the Magnus® line of Smart Passive Sensing™ ICs (Integrated Circuits). The Magnus-S3 M3D IC incorporates three sensors:

1. The Chameleon engine generates a SENSOR CODE that quantifies the adaptive RF impedance setting used to match the sensor antenna. This is particularly useful for monitoring moisture levels.
2. An on-chip Received Signal Strength Indicator RSSI monitor indicates the amount of RF power reaching the chip. It also allows the wireless reader to manage its output power for optimum sensor performance.
3. The on-chip temperature sensor generates a TEMPERATURE CODE data value proportional to the temperature.

AZN3300-E Magnus®-S3 M3E Passive Sensor IC

The Magnus®-S3 M3E Sensor IC (Integrated Circuit) employs Smart Passive Sensing™ technology to enable a new class of maintenance-free and battery-free sensors. The Magnus-S3 M3E IC incorporates two sensors:

1. An on-chip Received Signal Strength Indicator RSSI monitor indicates the amount of RF power reaching the chip.
2. The on-chip temperature sensor generates a TEMPERATURE CODE data value proportional to the temperature. The IC can be calibrated to provide precise temperature measurements.
